Shinko Jidar

SHINKO JIDAR is a pre-painted roll formed steel specially developed for fencing and walling applications.

Shinko Jidar is a Pre-Painted galvanized steel with a printed pattern of Red Brick providing an appearance of natural brick wall.

Galvanized Steel, Minimum G30

Fencing and Walling

Dimensions: (For normal supply products )

Thickness (mm)	Width (mm)
From 0.30 to 0.50	1219 mm

For specific dimensions please contact Sales and Marketing Dept.

Pretreatment	Corrosion resistance proprietary conversion coating each side.
Base Coat	Polyester Based custom Formulated System Nominal thickness- 10 microns at exterior side BRICK RED COLOR
Pattern (Grid Finish)	Modified polyester based ink of 2 – 3 microns thickness in pattern. WHITE OR BLACK COLOR grid lines can be provided.
Finish Coat	Polyester Clear coat. Nominal thickness – 10 microns
Backing Coat	Custom Formulated Grey Backer Nominal thickness – 5 microns.
Gloss (60˚)	High Gloss
